RIR-E13 • Reaming Inserts

Padded Reaming Tools

Workpiece Materials

P Steel
M Stainless Steel
K Cast Iron
S High-Temp Alloys
Select Filters
Filters
Filters
View filters in
Metric
Inch
Key Filters
Workpiece Material
Workpiece Material
  • P Steel (1)
    • P0
      Low-Carbon Steels, Long Chipping C < .25%; <125 HB; <530 N/mm^2 UTS
      (1)
    • P1
      Low-Carbon Steels, Short Chipping C < .25%; <125 HB; <530 N/mm^2 UTS
      (1)
    • P2
      Medium and High Carbon Steels C < .25%; <220 HB; <25 HRC; >530 N/mm^2 UTS
      (1)
    • P3
      Alloy Steels & Tool Steels C > .25%; <330 HB; <35 HRC; 600-850 N/mm^2 UTS
      (1)
    • P4
      Alloy Steels & Tool Steels C > .25%; 350-420 HB; 35-43 HRC; 850-1400 N/mm^2 UTS
      (1)
    • P5
      Ferritic, Martensitic, and PH Stainless Steels <330 HB; <35 HRC; 600-900 N/mm^2 UTS
      (1)
    • P6
      High Strength Ferritic, Martensitic, and PH Stainless Steels 350-450 HB; 35-43 HRC; 900-2400 N/mm^2 UTS
      (1)
  • M Stainless Steel (1)
    • M1
      Austenitic Stainless Steel 130-200 HB; <600 N/mm^2 UTS
      (1)
    • M2
      High Strength Austenitic Stainless and Cast Stainless Steels 150-230 HB; <25 HRC; >600 N/mm^2 UTS
      (1)
    • M3
      Duplex Stainless Steel 135-275 HB; <30 HRC; 500-1200 N/mm^2 UTS
      (1)
  • K Cast Iron (1)
    • K1
      Gray Cast Iron 120-290 HB; <32 HRC; 125-500 N/mm^2 UTS
      (1)
    • K2
      Low and Medium Strength CGI and Ductile Irons 130-260 HB; <28 HRC; <600 N/mm^2 UTS
      (1)
    • K3
      High Strength Ductile and Austempered Ductile Iron 180-350 HB; <43 HRC; >600 N/mm^2 UTS
      (1)
  • S High-Temp Alloys (1)
    • S1
      Iron-Based, Heat-Resistant Alloys 160-260 HB; 25-48 HRC; 500-1200 N/mm^2 UTS
      (1)
    • S2
      Cobalt-Based, Heat-Resistant Alloys 250-450 HB; 25-48 HRC; 1000-1450 N/mm^2 UTS
      (1)
    • S3
      Nickel-Based, Heat Resistant Alloys 160-450 HB; <48 HRC; 600-1700 N/mm^2 UTS
      (1)
    • S4
      Titanium and Titanium Alloys 300-400 HB; 33-43 HRC; 900-1600 N/mm^2 UTS
      (1)
No filters matching ""
Change the visible columns with any of the parameters listed below. A maximum of 7 columns can be displayed.
Displaying 1- 1 of 1 results
Select Columns
Select Filters
Metric
Inch
Show
Metric
Inch
SAP Material Number ISO Catalog Number ANSI Catalog Number Grade [L10] Insert Cutting Edge Length [L10] Insert Cutting Edge Length [S] Insert Thickness [S] Insert Thickness [W] Insert Width [W] Insert Width [Clearance Angle Major Clearance Angle Major Second [GAA] Insert Rake Angle
3856793 RIR04E1312 RIR04E1312 KC6005 27.0000 1.063 3.1300 .1230 5.5600 .2190 8.000 18.000 12.000
    List price:
    $39.96 /each
    Your price:
    Qty
    List price:
    Discount: %
    Your price:
    Replacement This item is no longer available
    Replacement Product Please contact customer service for assistance
    Qty

    Sold in pkg. of

    Grades

    • KC6005
      KC6005

      • TiN-PVD-coated carbide.

      • Highly wear-resistant substrate.

      • Reaming grade with universal applications in high-precision carbide cutting.

      P Steel
      S High-Temp Alloys
      K Cast Iron
      M Stainless Steel
    • KC6105
      KC6105

      • TiN-PVD-coated carbide.

      • Highly wear-resistant substrate.

      • Reaming grade with universal applications in high-precision carbide cutting.

      P Steel
      K Cast Iron
      M Stainless Steel
    • KC6305
      KC6305

      • TiAlN-PVD-coated carbide.

      • Reaming grade with highly wear-resistant substrate.

      • Particularly suitable for cast iron and steel.

      • For exceptionally high-precision finishing.

      • High-precision carbide cutting values.

      P Steel
      S High-Temp Alloys
      K Cast Iron
      M Stainless Steel
