Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)
Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)
Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)
Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)

T604 • Metric DIN 371, 374 and 376 • Form C Semi-Bottoming Chamfer

Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)

Features and benefits

  • KSH26 TiAlN/MoS2 for tapping steel 32–44 HRC (3 x D).

Uses and application

  • Threading: Blind HoleThreading: Blind Hole
  • HSS-E-PMHSS-E-PM
  • Chamfer Form C (2–3)Chamfer Form C (2–3)
  • DIN number 371DIN number 371
  • DIN number 374DIN number 374
  • DIN number 376DIN number 376
  • Tapping Helix Angle: 42°Tapping Helix Angle: 42°
  • Flood Coolant: TappingFlood Coolant: Tapping
  • Class of Fit: 6HClass of Fit: 6H
  • Manufacturer’s Specs: MManufacturer’s Specs: M
  • Manufacturer’s Specs: MFManufacturer’s Specs: MF

Workpiece Materials

P Steel
Spiral-Flute HSS-E-PM Taps • Blind Holes (3 x D)
