The 7792VX series is designed for high-feed milling applications with superior surface generation

  • 7792VX covers multiple applications: facing, pocketing, ramping, helical interpolation, and plunging.
  • Perfect solution when high metal removal rates and reduced cycle times are a requirement.
  • When using long (extended) toolholders, 7792VX reduces deflection by redirecting cutting forces to the spindle.
  • Coarse and fine pitch cutters available with internal coolant.
  • Inserts with integrated wiper facet generate excellent surface finishes up to 16Ra (1,6 μm).





Straight Edge Inserts for 7792VX Fit Existing Pockets and Feature:

  • IC 06, 09, 12, 16 inserts with straight cutting edge for consistent chip thickness
    for all depth-of-cut applications
  • Flat Top Geometry (-M) with the strongest cutting edge for longer tool life
  • Positive Rake Face (-M41) with chip control for better chip clearance
