Rotating Tungsten Carbide Pick • 20mm (.76 in) Shank

Positive Lock Retainer for Grooved Blocks • Plug Tip for Hard Cutting

Metric
Inch
SAP Material Number 1010784
ISO Catalog Number RL10
ANSI Catalog Number RL10
Grade K3560
Point Included Angle [SIGMA] 90
EW_CON_POINT_INCL_ANGLE_B 40
[TD] Tip Diameter 12.014 mm
[TD] Tip Diameter .473 in
[TL] Tip Length 17.805 mm
[TL] Tip Length .701 in
[L1] Gage Length 44.463 mm
[L1] Gage Length 1.75 in
[D2] Body Diameter Workpiece Side 26.975 mm
[D2] Body Diameter Workpiece Side 1.062 in
[D] Shank/Bore Diameter 19.431 mm
[D] Shank/Bore Diameter .765 in
[LS] Shank Length 40.335 mm
[LS] Shank Length 1.588 in
[OAL] Overall Length 84.798 mm
[OAL] Overall Length 3.338 in
