| Material Number | 4064000 |
| ISO Catalog ID | SDB66RBHT12F |
| ANSI Catalog ID | SDB66RBHT12F |
| [DM] Minimum Bore Diameter | 65.5 mm |
| [DM] Minimum Bore Diameter | 2.5787 in |
| [DMAX] Maximum Bore Diameter | 87.5 mm |
| [DMAX] Maximum Bore Diameter | 3.4449 in |
| Gage Insert | CC..1204../CC..43. |
| Insert Screw ID Drive Size | T20 |
