HARVI I | HARVI I TE | HARVI II | HARVI II TE | HARVI II LONG | HARVI III | HARVI III AERO | HARVI IV | |
|---|---|---|---|---|---|---|---|---|
 |  |  |  |  |  |  |  | |
| Flute | 4 | 4 | 5 | 5 | 5 | 6 | 6 | 8 |
| Materials | Steels Stainless Steels Cast Iron High Temp Alloys and other HRSA Hardened materials up to 48HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 48HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 48HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC |
| Applications | Slotting Side & Shoulder Milling Plunging High Efficiency Milling Trochoidal Milling Ramping 3D Profiling | Slotting up to 2xD Side & Shoulder Milling Plunging High Efficiency Milling Trochoidal Milling 3D Profiling High angle ramping up to 45º | Slotting Side & Shoulder Milling High Efficiency Milling Trochoidal Milling Ramping up to 3° | Slotting up to 2xD Side & Shoulder Milling High angle ramping up to 45° High Efficiency Milling Trochoidal Milling Plunging | Side & Shoulder Milling High Efficiency Milling Trochoidal Milling | High Efficiency Milling Dynamic Milling Side & Shoulder Milling Ramping Trochoidal Milling 3D Profiling | High Efficiency Milling Dynamic Milling Side & Shoulder Milling Ramping Trochoidal Milling 3D Profiling | High Efficiency Milling Dynamic Milling Side Milling Peel Milling Ramping up to 2° |
| Diameter Range | 1/8 - 1” (4-25mm) | 1/16 – 1.25” (2-25mm) | 1/4 - 1” (4-25mm) | 1/8 - 1.25" (4-25mm) | 1/4-1” (6-25mm) | 3/8–1.25” 1/8–1.25" incl. Taper BN | 1/4–1.5” | 3/8-1" (10-25mm) |
| Best For | General versatility and reliability is required for roughing and finishing of multiple materials | Maximum versatility and process security is required, but there is a low chance of dynamic milling and high chance for heaviest and most aggressive cuts | General versatility for roughing and finishing of multiple materials with higher metal removal rates | Maximum versatility is required with a high chance of dynamic milling. Better choice for narrow trochoidal slots for better chip management. | Long reach applications, best choice for finishing and fine finishing operations | When dynamic milling & high efficiency milling with high productivity. Better choice for wider trochoidal slots. | Same as HARVI III, but ideal for Titanium | When only dynamic milling and high efficiency milling with highest productivity, best choice for pocketing applications |
HARVI I | HARVI I TE | HARVI II | HARVI II TE | HARVI II LONG | HARVI III | HARVI III AERO | HARVI IV | |
|---|---|---|---|---|---|---|---|---|
| | | | | | | | |
| Flute | 4 | 4 | 5 | 5 | 5 | 6 | 6 | 8 |
| Materials | Steels Stainless Steels Cast Iron High Temp Alloys and other HRSA Hardened materials up to 48HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 48HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels Cast Iron High Temp Alloys Hardened materials up to 48HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC | Steels Stainless Steels
High Temp Alloys Hardened materials up to 55HRC |
| Applications | Slotting Side & Shoulder Milling Plunging High Efficiency Milling Trochoidal Milling Ramping 3D Profiling | Slotting up to 2xD Side & Shoulder Milling Plunging High Efficiency Milling Trochoidal Milling 3D Profiling High angle ramping up to 45º | Slotting Side & Shoulder Milling High Efficiency Milling Trochoidal Milling Ramping up to 3° | Slotting up to 2xD Side & Shoulder Milling High angle ramping up to 45° High Efficiency Milling Trochoidal Milling Plunging | Side & Shoulder Milling High Efficiency Milling Trochoidal Milling | High Efficiency Milling Dynamic Milling Side & Shoulder Milling Ramping Trochoidal Milling 3D Profiling | High Efficiency Milling Dynamic Milling Side & Shoulder Milling Ramping Trochoidal Milling 3D Profiling | High Efficiency Milling Dynamic Milling Side Milling Peel Milling Ramping up to 2° |
| Diameter Range | 1/8 - 1” (4-25mm) | 1/16 – 1.25” (2-25mm) | 1/4 - 1” (4-25mm) | 1/8 - 1.25" (4-25mm) | 1/4-1” (6-25mm) | 3/8–1.25” 1/8–1.25" incl. Taper BN | 1/4–1.5” | 3/8-1" (10-25mm) |
| Best For | General versatility and reliability is required for roughing and finishing of multiple materials | Maximum versatility and process security is required, but there is a low chance of dynamic milling and high chance for heaviest and most aggressive cuts | General versatility for roughing and finishing of multiple materials with higher metal removal rates | Maximum versatility is required with a high chance of dynamic milling. Better choice for narrow trochoidal slots for better chip management. | Long reach applications, best choice for finishing and fine finishing operations | When dynamic milling & high efficiency milling with high productivity. Better choice for wider trochoidal slots. | Same as HARVI III, but ideal for Titanium | When only dynamic milling and high efficiency milling with highest productivity, best choice for pocketing applications |
Kennametal has a deep-rooted history in turning and continuously pushes the boundaries of materials science and machining technology. Founded in 1938 by metallurgist Philip M. McKenna, Kennametal revolutionized machining with a tungsten-titanium carbide alloy. This breakthrough not only transformed the manufacturing industry but also navigated Kennametal on a journey that continues to lead the way in turning tool technology, offering advanced solutions that meet the most challenging environments in manufacturing today.
As pioneers in metal cutting, we know that success in high-performance turning operations requires accuracy, precision and reliability to achieve clean cuts and deliver the best results every time.
*Promotion valid in the United States, Mexico and Canada only from July 1, 2025, through December 31, 2025, and limited to Kennametal turning tools and inserts only. This offer cannot be combined with any other offer. Promotional code required to qualify purchase ($500 minimum) to receive a Kennametal x Leatherman multi-tool ($100 value). Program is void where prohibited by law and all local, state and federal laws apply. Kennametal reserves the right to alter or cancel this promotion at any time. Offer applicable to drop-shipped orders only.
