| SAP Material Number | 6588981 |
| ISO Catalog Number | TACU017ER32DA61301851 |
| ANSI Catalog Number | TACU017ER32DA61301851 |
| [CST] Catalog Collet Series | ER32 |
| Machine Mount Code | 017 |
| [B1] Front Clearance | 84.0000 mm |
| [B1] Front Clearance | 3.307 in |
| [B2] Overall Width | 123.0000 mm |
| [B2] Overall Width | 4.842 in |
| [D] Adapter / Shank / Bore Diameter | 40.0 mm |
| [D] Adapter / Shank / Bore Diameter | 1.574 in |
| [D11] Lock Nut Diameter | 50.0000 mm |
| [D11] Lock Nut Diameter | 1.968 in |
| Lock Nut Diameter [DLN_2] | 47.0000 mm |
| HLD_LOCK_NUT_DIA_2_I | 1.850 in |
| [F] F Dimension | 50.0000 mm |
| [F] F Dimension | 1.968 in |
| [H2] Overall Height | 78.0000 mm |
| [H2] Overall Height | 3.070 in |
| [L] Overall Length | 200.0000 mm |
| [L] Overall Length | 7.874 in |
| [L1] Gage Length | 119.5000 mm |
| [L1] Gage Length | 4.704 in |
| Torque Machine Spindle Nm | 50.000 |
| Coolant Pressure Bar | 70.0 |
| Coolant Pressure PSI | 1000.0 |
| Coolant Delivery | I/E |
| [CS1] Coolant Supply Exit Size | G 1/8 |
| Max RPM | 6000 |
| Weight Kilograms | 7.03 |
| Torque Newton Meters | 136.000 |
| Torque Foot Pounds | 100.0000 |
