Features and benefits

  • Keyway cutter for slot machining of shaft to hub connections.

  • For production of key slots according to ISO standards.

  • Roughing and finishing with one tool.

  • Center cutting for plunging and ramping operations.

  • Unequal flute spacing for chatter-free machining at highest feed rates.

Uses and application

  • Plunge MillingPlunge Milling
  • Ramping: BlankRamping: Blank
  • Slotting: Square EndSlotting: Square End
  • Side Milling/Shoulder Milling: Square EndSide Milling/Shoulder Milling: Square End
  • Corner Style: Corner RadiusCorner Style: Corner Radius
  • Helix Angle: 38°Helix Angle: 38°
  • Tool Dimensions: Flute Configuration: 3Tool Dimensions: Flute Configuration: 3

Workpiece Materials

P Steel
M Stainless Steel
K Cast Iron
S High-Temp Alloys
H Hardened Materials
